Split-core structure, easy to install on site and easy to operate. Quick and easy installation or removal without disconnecting the primary cable under test, effective for safe and easy current testing;
Flexible structure design, can detect the current of irregular primary conductor;
Low output voltage, high linearity, wide frequency range, no saturation (without integrator);
The secondary output adopts shielded wire, and the length can be customized according to customer requirements.
|Working Temperature||-40℃～+70℃||Relative Humidity||≤90%|
|Voltage Level||0.4/0.66/0.72KV||Accuracy Class||5%(without integrator)|
|Rated Input Current||10～2000A||Phase Error||≤60'（45HZ～65Hz）|
|Linear Range||5%～120%||Response Bandwidth||1HZ～1MHz|
|Auxiliary Integrator Power Supply||5～15VDC||Insulation Strenth||1000MΩ/500V/min|
|Shell||PC Flame Retardant Grade94-V0||Output Mode||Three-core Shielded Cable|
|Skeleton and Quilt||Silicone Rubber||Puncture Needle||Stainless Steel“304”|
|Current Output||Blue Wire - Yellow Line||Power Output||Red Wire|
When the transformer is powered on, you must wear insulating gloves, and your hands must not directly touch the red core of the shielded wire;
Do not use if the output leads are damaged. Our company is not responsible for any safety problems caused by improper operation.
